Place of Origin: | Guangdong , China (Mainland) |
---|---|
Brand Name: | DDW |
Certification: | ISO9001 , CE , RoHS , FCC , IP65 |
Model Number: | DDW-AD5501S |
Minimum Order Quantity: | 1 |
Price: | Negotiable |
Packaging Details: | Carton and Full wood box packing |
Delivery Time: | 20-30working days upon payment |
Payment Terms: | T/T , Western Union , L/C , Alibaba Trade Assurance |
Supply Ability: | 300 set per month |
Application: | Outdoor | Panel Brand: | Samsung LG |
---|---|---|---|
Storage Temperature: | -40℃ — 50℃ | Average Brightness: | 1500-2500cd/m*m |
Maximum Resolution: | 1920x1080 | Maximum Power Consumption: | 3600W |
Input Voltage: | AC 110V-240V | ||
High Light: | electric vehicle charging pile,electric vehicle charging stations |
LCD parameters
|
Model No.
|
DDW-AD5501S
|
display
|
55" LED
|
|
Contrast Ratio
|
16:9
|
|
machine size
|
1900x800x45mm | |
Display area
|
1207.6x678.4mm
|
|
Maximum resolution
|
1920x1080
|
|
Pixel Pitch(mm)
|
0.63x0.63mm
|
|
Display color
|
1.073G(10bits/color)
|
|
Life(hrs)
|
>60,000(hrs)
|
|
average brightness
|
1500-2500cd/m*m
|
|
contrast
|
4000:1
|
|
Viewing angle
|
H178°/V178°
|
|
Power supply
|
AC100~240V 50 /60 HZ
|
|
Maximum power consumption
|
3600W
|
|
Standby power consumption
|
<5W
|
|
Working temperature
|
0- 40 ℃
|
|
Storage temperature
|
-40℃ — 50℃
|
|
Installation
|
flood-standing, wall mounted or customized
|
|
IP65 waterproof case
|
Using 1.5mm galvanized steel
|
|
Surface spray powder (anti-corrosion, anti-rust)
|
||
Outdoor anticorrosive over 7 years
|
||
AR anti-reflective glass 3 + 3mm plastic folder
|
||
Display screen glass
|
Light transmittance 97%
|
|
Reflectivity is less than 3%
|
||
Explosion-proof, waterproof, fireproof
|
||
UV protection 99%
|
||
Display screen
|
Industrial-grade LED, Original Samsung screen,brightness 2000cd / m2
|
|
High brightness 1500-2000 cd/㎡
|
||
Full hd 1920 x1080
|
||
Industrial power supply
|
||
automatically adjust the brightness
|
||
Electronic control system
|
Power supplies , timers , remote control panel , photographic plate , speaker , battery , leakage protection switches , sockets , etc.
|
|
Cooling system
|
Intelligent heating and air-cooling system
|
|
meet the environment of -20℃ — 55 ℃
|
||
LCD display is not blackening
|
||
Patented cooling system ensures that the LCD screen without blackening in direct sunlight
|
||
Product assembly and aging test
|
IP65 waterproof test
|
|
High and low temperature test
|
||
Simulated solar radiation test
|
||
Aging test
|
||
Packaging
|
Wooden packaging , sea/air/express(transportation standards)
|
